Welcome to the team! Bera Verschleißteile and STABline now under the umbrella of the new FELASTO PUR GmbH!

Original STABline quality

Support plates Stable, durable and easy to handle

STABline support plates offer you a reliable and effective solution for stable machine support on uneven and soft ground. With their high load capacity and easy handling, they guarantee safe use on any construction site.
get in touch

Load distribution with a system

Heavy-duty for safe and solid load distribution

Whether on soft ground, uneven terrain or sensitive surfaces – STABline offers robust and practical solutions for different requirements on the construction site. Our products such as support pads, support blocks, support pads mini and container supports ensure safe load distribution, reliable stability and lasting surface protection. Our plastic plates are made of high-quality HD-PE and are characterised by their high quality. We supply the panels in a smooth finish as standard. However, other variants are also available on request – for example with deep-milled recesses, in an anti-slip version or with a textured surface.

High-quality plastic for maximum safety.

STABblocks

The rectangular format with a thickness of 80 or 100 mm provides stable support for heavy equipment on uneven terrain. The specially developed STABline anti-slip surface increases the stability of the support plate. This special version is available on request.

Length	Width	Height	Weight
500* mm	250* mm	80* mm	10 kg
1000* mm	250* mm	80* mm	13 kg
1000* mm	250* mm	100* mm	25 kg
1200* mm	330* mm	100* mm	39 kg

* Example dimensions, other dimensions available on request.

STABpads Mini

For truck cranes, small mobile cranes and work platforms, STABpads Mini are support plates that attach directly to the support foot. The support foot snaps into the plate so that the plate moves with the support foot. Perfect for site relocation.

Shape	Length	Width	Diameter	Strength	Weight	Load/plate
Round			400* mm	80 mm	10 kg	4 t
Round			500* mm	80 mm	15 kg	12 kg
Square	400 mm	400 mm		80 mm	12 kg	18 kg
Square	500* mm	500* mm		80 mm	18 kg	30 kg

* Example dimensions, other dimensions available on request.

STABpads

The safety of your employees and machinery is our top priority. Avoid risks due to inadequate support of your vehicles. STABpad support and load distribution plates offer you the ideal solution for unstable floor conditions. Depending on the plate, they support up to 90 tonnes.

Length	Width	Height	Weight	Load/plate
300 mm	300 mm	25 mm	2 kg	4 t
400* mm	400* mm	50* mm	8 kg	12 t
500* mm	500* mm	50* mm	12 kg	18 t
800* mm	800* mm	60* mm	38 kg	30 t
1000* mm	1000* mm	80* mm	74 kg	70 t

* Example dimensions, other dimensions available on request.

STABblocks

When placing containers, the ground often needs protection. STABline container supports provide a secure stand and protect sensitive surfaces from consequential damage. Suitable for 160 mm castors as standard – special solutions are available on request.

Length	Width	Strength	Weight
350 mm	250 mm	80 mm	5 kg
